BK E-Flite Carbon-Z Cub SS AS3X BNF Basic 2150 mm

Produkt Details

Die E-flite Carbon-Z Cub SS 2.1m macht es einfacher als je zuvor, ein wirklich einzigartiges und vielseitiges Flugerlebnis im riesigen Maßstab zu genießen. Basierend auf der originalen Carbon-Z Cub ist das Modell jetzt mit einer Fülle neuer Funktionen ausgestattet, die den Komfort und die Flugeigenschaften und -leistung verbessern und es noch besser machen als je zuvor!

Key Features

Ein Update der wegweisenden original Carbon Z-Cub in verfeinerter Version

Im Großmodell-Format mit 2,1 m Spannweite und leichter, außergewöhnlich robuster, faserverstärkter Carbon-Z-Konstruktion mit Hohlkern

Einfach zu fliegen mit der optionalen SAFE® Select-Fluglagenbegrenzung

Unübertroffene Stabilität und Präzision der AS3X®-Technologie für ein ruhigeres Flugverhalten

Spektrum™ AR637T DSMX 6-Kanal AS3X & SAFE Telemetrie Empfänger

In The Box

(1) E-flite Carbon-Z Cub SS 2.1m mit:

(1) 60A Brushless ESC (installiert)

(1) Brushless Outrunner Motor (enthalten)

(6) Digitale Metallgetriebe Servos (installiert)

(1) AR637T DSMX 6-Kanal AS3X & SAFE Telemetrie Empfänger

(1) Bedienungsanleitung

Needed to Complete

6-Kanal-DSMX® / DSM2®-Sender mit Full-Range

4-6S 14.8-22.2V 3200-7000mAh LiPo mit EC5™ oder IC5™ Stecker

Kompatibles LiPo Ladegerät

Introduction

The original Carbon-Z® Cub was ground-breaking and created a new category for large-scale, electric-powered models. Based on a platform that was known for legendary versatility, its lightweight and exceptionally strong, composite-reinforced and hollow-core design was mostly factory-finished and assembled so it was easier for more pilots to go "BIG" than ever before. The E-flite® Carbon-Z Cub SS 2.1m is an updated and refined version of the original, equipped with a long list of new features for improved flight performance, capabilities and convenience so you can enjoy a giant-scale flying experience unlike any other.

Features

An updated and refined version of the ground-breaking and category-creating original Carbon-Z Cub

Giant-scale 84"/2.1m wingspan with lightweight and exceptionally strong composite-reinforced, hollow-core Carbon-Z construction

Drooped wing tip design increases wing and aileron area for significantly improved slow speed performance and control

Thumbscrews with decorative gas caps and snap-on antennas to easily install/remove the two-piece wing without tools

Modified flap design allows them to travel both ways for full-span aileron and other mixing options

Articulated and shock-absorbing landing gear with improved and strengthened mounts

Even larger oversized, tundra-style wheels with softer tires for better ground handling

Fully-molded top and bottom landing gear covers for a more scale-like appearance

More secure rear mount and cross braces for the optional floats (sold separately)

Quick-release, multi-position battery mounting tray (inspired by Morgan Mill RC) fits 4–6S 3200–7000mAh batteries

Improved motor design with added bearing for smoother, more reliable performance

15x7 propeller molded from material that better maintains balance and stiffness

IC5 connector (compatible with EC5 connectors) on the 60-amp ESC for better and more reliable power delivery

Vibrant, high-visibility Carbon Cub SS Signature trim and color scheme

Spektrum™ AR637TA 6-Channel AS3X & SAFE Telemetry Receiver

Easy to fly with innovative, optional-use SAFE® Select flight envelope protection

The unmatched stability and locked-in feel of exclusive AS3X® technology

Six factory-installed digital, metal-geared servos with ball-link equipped linkages

Convenient push-button released, top-mounted hatch for easy battery access

Extremely wide scale and mild to beyond-scale aerobatic and wild flight envelope

Tow up to 3-meter span sailplanes with the included aerotow mechanism (servo sold separately)

Overview

The E-flite® Carbon-Z® Cub SS 2.1m makes it easier than ever to enjoy a truly unique and versatile giant-scale flying experience. Based on the original Carbon-Z Cub, it's equipped with an abundance of new convenience, capability and flight performance-improving features. An updated wing design with drooped tips adds wing and aileron area for significantly improved slow speed handling, performance and control. The modified flap design allows them to travel both ways for full-span aileron and other mixing options, and thumbscrews make it easier to install and remove the two-piece wing without tools.

Articulated and shock-absorbing landing gear, equipped with even larger oversized tundra-style wheels with softer tires, offers better ground handling that soaks up the bumps of rough surfaces. The push-button released, top-mounted hatch offers convenient and easy access to the battery compartment – which now holds a quick-release, multi-position battery mounting tray that fits 4S to 6S 3200–7000mAh batteries. An improved motor design featuring an additional bearing, plus a propeller molded from material that better maintains balance and stiffness, results in smoother and more reliable power system performance. The composite-reinforced, hollow-core airframe arrives mostly factory-finished and assembled, and the installed digital, metal-geared servos with ball-link equipped linkages deliver crisp and precise control.

So whether you fly it slow and scale, or perform beyond-scale vertical takeoffs and aerobatics, the Carbon-Z Cub SS will offer unexpected levels of versatility, capability and performance you'll enjoy flight after flight!

Produkt Eigenschaften

Airfoil Shape Modified Clark-Y

Approximate Assembly Time Less than 1 hour

Approximate Flight Time 4 - 10 minutes

Battery Sold Separately

CG (Center of Gravity) 4.1 - 4.7" (105 - 120mm) from leading edge of wing measured at fuselage

Charger Sold Separately

Completion Level Bind-N-Fly Basic

Flaps Yes

Power Type Electric

Landing Gear Fixed main with steerable tail wheel

Minimum Required Radio 4-channel

Motor Size BL50

Product Length 56.3" (1430 mm)

Propeller Size 15x7E

Radio Sold Separately

Receiver Included

Recommended Motor Battery 4-6S 4000 - 7000mAh LiPo, 6S LiPo recommended if taking off from water

Servos Included

Skill Level Level 2

Speed 50mph (80kph)

Speed Control Included

Spinner Size 2.4" (61 mm)

Steering Steerable tailwheel

Technology SAFE Select

Trim Scheme Colors White, orange, black and gray

Wing Area 1130 sq in (72.9 sq dm)

Wing Loading 16.6 - 19.3 oz/sq ft (50.7 - 59.0 g/sq dm)

Wingspan 84.6" (2149 mm)
